Listings - Harley Davidson
These tables are for basic reference. By using the information customers can check the suitability for other bikes and special applications. Please check with us first for any minor differences in specs. In ALL cases please advise us of the maximum payload and your riding style so that we can select the correct shocker and spring for your specific application.



CLASSIC CRUISER [CMT] Open Length Mount Type Spring Dia. Typical Applications
CMT300 300mm Eye - Eye 1.99" XL883 C&L [2007-09] XL883 Sportster Custom [04-09] XL1200 Sportster Custom [04-09] XL1200 C&L [07-09]
CMT325 325mm Eye - Eye 1.99" ALL Sportsters XLCR, XLH1000, XLS1000 Roadster, XLH883 Sportster Hugger [88-91], XR1000 [83-84]
CMT350 350mm Eye - Eye 1.99" LH883 Sportster and Deluxe [88-93], XR1200 [08-09]
CMT325/1320 325mm Eye - Eye 1.99" BMW K100 competition version


Please note - many models use the same shocker body but different rated springs - please ensure you tell us which model and likely additional weight - e.g. panniers, passengers etc.

For riders requiring shorted shockers to lower their bikes - please contact us for details.



The data listed on this site is given in good faith, but vehicle details and final application specifications must be checked and agreed by the user. ALL RAM SHOX are fully re-buildable and carry a 2 year unconditional warranty.



Realm Engineering Ltd or their agents accept no liability for incorrectly fitted or selected shock units.



Competition versions of ALL shox are available - please contact us
